Characteristic
Contact Resistance: Under 15mΩ (Initial)
Insulation Resistance: More than 100mΩ (under 500VDC)
Field Intensity 2,000VAC, 50/60Hz for 1 min
Vibration: 10~55Hz, 1.5mm(DA)
Ambient Temperature: -10~+80°C (No icing)
Humidity under 85%
Life: Mechanically: more than 500,000 times, Electrically: more than 100,000 times
Rated Ralue
| Load |
AC Load |
DC Load |
| Resistive Load |
15A 250V 20A 125V |
0.5A 250V 0.9A 125V |
| Inductive Load |
15A 250V 20A 125V |
0.3A 250V 0.5A 125V 15A |
| Bulb Load |
400W 125A 800W 250V |
- |
| Motor Load |
400W 125V(single phase)
750W 250V(three phase) |
- |
