CT-1301
Item Model:CT-1301

Action Characteristic

OF(Max): 300g

RF(Min): 50g

PT(Max): 4mm

OT(Min): 1.6mm

MD(Max): 1.3mm

FP(Max): 20.6mm

OP(mm): 17.4±0.8

Product Description

‧Variety of actuator choices, action position is adjustable (CT-1701)

‧High switching capacity(15A), high accuracy, wide range of operating speed

‧Every model of CT-1 Series offer optional solder terminal , screw terminal and stripping quick terminal. By adding A is solder terminal(CT-1701A), C represents stripping quick terminal(CT-1701C) and blank means screw terminal(CT-1701).
