CT-1702
Item Model:CT-1702

Action Characteristic

OF(Max): 100g

RF(Min): 28g

PT(Max): 5mm

OT(Min): 2mm

MD(Max): 1mm

FP(Max): 24.8mm

OP(mm): 19±0.4

Product Description

‧Variety of actuator choices, action position is adjustable (CT-1701)

‧High switching capacity(15A), high accuracy, wide range of operating speed

‧Every model of CT-1 Series offer optional solder terminal , screw terminal and stripping quick terminal. By adding A is solder terminal(CT-1701A), C represents stripping quick terminal(CT-1701C) and blank means screw terminal(CT-1701).
