CT-1704
Item Model:CT-1704

Action Characteristic

OF(Max): 160g

RF(Min): 42g

PT(Max): 2.7mm

OT(Min): 2.4mm

MD(Max): 0.5mm

FP(Max): 32.5mm

OP(mm): 30.2±0.4

Product Description

‧Variety of actuator choices, action position is adjustable (CT-1701)

‧High switching capacity(15A), high accuracy, wide range of operating speed

‧Every model of CT-1 Series offer optional solder terminal , screw terminal and stripping quick terminal. By adding A is solder terminal(CT-1701A), C represents stripping quick terminal(CT-1701C) and blank means screw terminal(CT-1701).
