CT-1705
Item Model:CT-1705

Action Characteristic

OF(Max): 10g

RF(Min): 3g

PT(Max): 20mm

OT(Min): 5.6mm

MD(Max): 3mm

FP(Max): -

OP(mm): 19±0.4

Product Description

‧Variety of actuator choices, action position is adjustable (CT-1701)

‧High switching capacity(15A), high accuracy, wide range of operating speed

‧Every model of CT-1 Series offer optional solder terminal , screw terminal and stripping quick terminal. By adding A is solder terminal(CT-1701A), C represents stripping quick terminal(CT-1701C) and blank means screw terminal(CT-1701).
