Operating Force OF(Max): 750g-cm
Release Force RF(Min): 100g-cm
Pre-travel PT(Max): 20˚
Tripping Position TP (±10%): 22.5O˚
Movement differential MD(Max): 10˚
Over travel OT(Min): 75˚
Total travel TT(Min): 95˚
‧ Metallic bottom cover
‧ Stainless steel roller, tool steel and spring
‧ Strong electric property 10A, 250V, for 500,000 times
