Operating Force OF(Max): 800g
Release Force RF(Min): 400g
Pre-travel PT(Max): 1.8mm
Tripping Position TP (±10%): 2.0mm
Movement differential MD(Max): 1.2mm
Over travel OT(Min): 4.0mm
Total travel TT(Min): 5.8mm
‧ Solid metal cover with maximum ±95˚C amplitude
‧ Mechanical Life extends to 20 million times
‧ Stainless steel roller, tool steel and spring
‧ PG11 gland can be equipped
