Operating Force OF(Max): 400g-cm
Release Force RF(Min): 100g-cm
Pre-travel PT(Max): 20˚
Tripping Position TP (±10%): 22.5˚
Movement differential MD(Max): 10˚
Over travel OT(Min): 75˚
Total travel TT(Min): 95˚
Rotary Indexing: 22.5˚
‧ Solid metal cover with maximum ±95˚C amplitude
‧ Mechanical Life extends to 20 million times
‧ Stainless steel roller, tool steel and spring
‧ PG11 gland can be equipped
