Operating Force OF(Max): 150g
Release Force RF(Min): 50g
Pre-travel PT(Max): 30mm
Tripping Position TP (±10%): 22.5˚
Movement differential MD(Max): 14˚
Over travel OT(Min): 20mm
Total travel TT(Min): 50mm
‧ Solid metal cover with maximum ±95˚C amplitude
‧ Mechanical Life extends to 20 million times
‧ Stainless steel roller, tool steel and spring
‧ PG11 gland can be equipped
