Operating Force OF(Max): 100g
Release Force RF(Min): 40g
Pre-travel PT(Max): 30mm
Tripping Position TP (±10%): 22.5˚
Movement differential MD(Max): 14˚
Over travel OT(Min): 20mm
Total travel TT(Min): 50mm
‧ Economical Plastic
‧ Stainless steel roller, tool steel and spring
‧ Pendulum up to ±95˚, amplitude
‧ PG13.5 gland that can be equipped
